HRVC-H2 Control Modules

Tinko HRVC-H2 voltage control module is designed as a closed-loop power distribution and voltage controlling system. There is no need of thermocouple input or other sensors. It is one module with two zones control, which can save space and cost. Users can operate two zones separately, independent display units and indicators.

Get A Quote
hot runner controller
hot runner controller
hrvc f2 control module

Features of HRVC-H2 Control Module

  • LED display

  • Built-in buzzer

  • Advanced PID control algorithm

  • Toggle power switch

  • Smart SOFT START function

  • Dual zone per module, save cost and space

  • No need thermocouple or other sensor input

  • Easy operation and convenient maintenance

Features of HRVC-H2 Control Module

Specifications HRVC-H2 Control Module

Control Zones

1-24 zones

Power Input

3-phase, 200-240Vac or 3-phase, 380-415Vac

Output Mode

Phase Angle

Control Range


Control Accuracy

Depends on module type

Load Capacity

240Vac, 15A, 3600W

Working environment

-0~55°C, 10~80% RH(No condensing)

Functions of HRVC-H2 Control Module

Alarms & Protection
  • Over-voltage protection, max. AC500V

  • Thermocouple open, reverse, short alarm

  • Heater open, short, overload alarm

  • Fuse blown alarm

  • Heating invalid alarm

  • Overload protection, cut off output

  • Short circuit protection, cut off output

  • Triac damage protection, cut off output

Video of HRVC-H2 Control Modules
Downloads of HRVC-H2 Control Modules
